New integrated cable protection solution from Balmoral

Balmoral, a provider of cable protection systems (CPS) for inter array and export cables for fixed and floating offshore wind installations, has created an integrated CPS the company reports is unique.


The Discovery Unit, a combination of product R&D, materials and testing specialists, created the integrated CPS.

The patented system, which is available in three standard sizes, includes a combination of bend restrictors and a bend stiffener, foundation interface device, standard dynamic unit and a detachable pull head, all of which is designed, manufactured and brought together in-house before being tested on the company’s test rig.

Dr Aneel Gill, product R&D manager, said: “Our systems are designed based on the fatigue limit state (FLS) and offer something different because of their unique diverless removal feature and the ability to account for free span caused by scour development.

“Our patented fibre reinforced technology adds stiffness to the system controlling the curvature during the project lifespan. This reduces the amount of movement experienced by the cable, improving fatigue performance and greatly reducing the risk of failure through the life of field.

“The low weight components of the system permit efficient transportation, handling and assembly on deck. The system also allows for diverless removal of the CPS should cable maintenance be required.”

Ian Milne, sales manager, added: “With over 300 employees at our Aberdeen facility we retain an impressive complement of design engineers, project managers, R&D, laboratory and testing personnel helping us maintain and strengthen our position as a leading subsea solutions provider for the energy sector.”
